RESIN SETTING OF ARIDS
Description
Monocomponent resin for aggregation of aggregates
Discover ours Monocomponent resin, the ideal solution for Setting and compaction of aggregates In various applications, such as:
- Grounds
- Alcorques
- Roads
- Tickets
- Splints
- Broken
This resin guarantees that the aggregate is firmly set and compacted, creating a pavement porous that allows an excellent Water absorption. It is designed to be outpatient, ensuring its durability and functionality outdoors.
Employment Method
No qualification for the application of the resin is required:
- Mix the aggregate with the resin, using a proportion of 7% of the weight of the aggregate (1L per 14 kg of aggregates).
- Apply to the surface, smoothing with a flat and rule, avoiding excesses of resin at the bottom (drain if necessary).
Under normal conditions, the reaction time is 4 to 6 hours for surface drying and 12 to 20 hours For total curing. After 24 hours, the pavement is passable.
Important clarifications
To cover 1 m² surface with a thickness of 4 cm, they will be needed 64 kg of aggregates and 4.5 L of resin.
Maintain a dilation joint of 2-3 mm In the frame. This product is not suitable for vehicle traffic or for areas with high pedestrian traffic. It is recommended to use aggregates with a granulometry between 3-12 mm.
WARNINGS
- For proper application, it is necessary that the aggregate be Washing and very dry.
- Do not apply at lower temperatures 7ºC To avoid quartering, although union between the stones would be achieved.
- Despite the powerful union provided by the product, natural movements such as root growth or strong dilations will not be absorbed by the system.
¿Cuanto material necesitas?
¿Cuanto material necesitas?
How much stone do I need?
How much stone do I need for the ground?
For shot and gravel song:
• ± 80kg per m², based on a 5cm layer.*For granulometries> 32mm a thicker layer is necessary.• Saca consumption: 1000kg = 0.625m³.
• Covering capacity: ± 12.5m² with a layer of 5 cm.
For pine cortex:
• ± 70L per m², based on a 5cm layer.
• Saca consumption: 1000L = ± 1m³ = ± 600kg
• Covering capacity: ± 14m² with a layer of 5 cm.
For volcanic, slate and chamota:
• ± 50kg per m², based on a 5cm layer.
• Saca consumption: 1000kg = ± 1m³
• Covering capacity: ± 20m² with a layer of 5 cm
How much stone do I need to fill a gabion?
Density of ± 1,650kg by 1m³.
The calculation is very simple to understand with an example, if you have a 100x50x30 cm gav. You have to make the following accounts:
1x0.5x0,3 = 0.15m³
0.15x1,650 = 247.50kg. stone.
*It is always good to calculate an extra 5%, since the gavions when filling them are a little and always enters some more stone than in the theoretical calculations.
Clarifications
ATTENTION!
Granulometries are sizes of sizes
Real sizes can vary slightly, since when talking, for example, 60-80mm stone, it means that the stones pass through a square mesh of 80x80mm. and do not go through a 60x60mm.
This 80x80 mesh can pass a 100mm stone. long and 65mm. wide so there may be a percentage of stones greater than 80 and less than 60mm.
Broken stones
On the other hand, in the stones of more than 60mm. There is a percentage of up to 10% stones that can be broken during classification, washing, loading and downloading, today we have no machinery that avoids those breaks.
In the photos you can see, only real products are seen, broken pieces have been removed.
Dust and sand in products
This product is not washed, so it contains dust, sand and even traces of other products due to processing and transport. This is not a problem when using it; The stone will be washed alone over time or can throw water before using it.
